100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter

    Buy cheap 100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter from wholesalers

    Buy cheap 100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter from wholesalers
    • Buy cheap 100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter from wholesalers
    • Buy cheap 100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter from wholesalers

    100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter

    Ask Lasest Price
    Brand Name : OPTICKING
    Model Number : KQSF0A-L031SL10X
    Certification : CE/FCC/RoHS/TUV/UL
    Supply Ability : 15000Piece/Pieces per Month
    Delivery Time : Within 1-8 working days after PO confirmed
    • Product Details
    • Company Profile

    100g Base Lr4 1310nm 100G QSFP28 LR4 4 Channels Transmitter

    Cost-Effective COB Packaging Technology for 100G QSFP28 LR4 10km 1310nm Optical Module
    This 100GBASE-LR4 QSFP28 takes COB+PCBA integrated designed COB (chip on board) packaging, which has the mature packaging process during automated production for cost-effective long-haul transmission.

    Product Features

    1. Hot-pluggable QSFP28 form factor
    2. 4 channels full-duplex transceiver module
    3. Supports 103.125Gb/s aggregate bit rate
    4. 4 channels transmitter
    5. Internal CDR circuits on both receiver and transmitter channels
    6. Support CDR bypass
    7. Built-in digital diagnostic functions
    8. Operating case temperature range: 0 to 70°C
    9. Single 3.3V power supply
    10. RoHS-6 compliant (lead free)

    Applications

    1. 100G Ethernet
    2. InfiniBand DDR

    Ordering Information


    Product NumberWavelengthData rateDistanceTX PowerRX SensLDPDDDM
    KQSF0A0085MM01X(SR4)850nm100Gb/s100M-8.4~2.4dBm<-5.2dBmVCSELPINYES
    KQSF0AL031SL10X(LR4)LAN WDM(note2)100Gb/s10KM-4.3~4.5dBm<-10.6dBmDFBPINYES
    KQSF0AL031SL10X(LR4)LAN WDM(note2)100Gb/s10KM-4.3~4.5dBm<-10.6dBmDFBPINYES
    KQSF0AC027SL00X(CWDM4)CWDM(note1)100Gb/s10KM-6.5~2.5dBm<-10.0dBmDFBPINYES
    KQSF0A0031SM00X(PSM4)1310nm100Gb/s2KM-4.3~4.5dBm<-10.6dBmDFBPINYES
